8. SciStream Tutorials

This guide provides practical tutorials for working with SciStream, a secure tunneling solution for scientific data transfer.

8.1 What is SciStream?

SciStream creates encrypted connections between endpoints, allowing data to flow securely between them, even across network boundaries. It's designed specifically for scientific data transfer needs, providing both security and performance.

8.2 Terminology Guide

Before diving into tutorials, it's important to understand key SciStream terminology:

INBOUND proxy (PROD): Sets up the receiving end of the tunnel (server side)
OUTBOUND proxy (CONS): Sets up the sending end of the tunnel (client side)
Listeners: Ports that accept incoming connections
Remote listeners: The remote destination ports that receive the forwarded connections

8.3 Understanding Data Flow

SciStream Tunnel Setup

Your client application connects to the local port on the client machine
The SciStream outbound request forwards this connection through the secure tunnel
The SciStream inbound request receives the forwarded connection
Data is delivered to your server application listening on the receiver port

8.4 Tutorial Environment

This tutorial uses a Vagrant-based virtual environment for demonstration purposes. For production environments, you would deploy SciStream directly on your infrastructure.

8.4.1 Prerequisites

Vagrant installed
VirtualBox or similar virtualization software
Basic familiarity with command-line operations

8.4.2 Setting Up the Vagrant Environment

A reference Vagrant file is provided in the root directory:

vagrant up

This creates several virtual machines that simulate a distributed environment.

8.5 SSL/TLS Configuration

Generate certificates for secure communication:

vagrant ssh producers2
openssl genrsa -out server.key 2048

Create a server.conf file:

[req]
distinguished_name = req_distinguished_name
x509_extensions = v3_req
prompt = no

[req_distinguished_name]
CN = 192.168.30.10

[v3_req]
subjectAltName = IP:192.168.30.10

Generate the certificates:

openssl req -new -key server.key -out server.csr -config server.conf
openssl x509 -req -days 365 -in server.csr -signkey server.key -out server.crt -extfile server.conf -extensions v3_req

8.6 Creating a Secure Tunnel

8.6.1 Step 1: Set Up the Inbound Request (Server Side)

Start the control server on the server side:

vagrant ssh producers2
s2cs --verbose --port=5007 --listener-ip=192.168.10.11 --type=Haproxy

Initialize the inbound request:

vagrant ssh producer
cp ./vagrant/server.crt ./server.crt
s2uc inbound_request --s2cs 192.168.10.11:5007 --remote_ip 192.168.10.10 --receiver_ports 5001 --mock True

You'll see output similar to:

uid; s2cs; access_token; role
4f8583bc-a4d3-11ee-9fd6-034d1fcbd7c3 192.168.10.11:5007 INVALID_TOKEN PROD
sending client request message
waiting for hello message
sending for hello message
Hello message sent successfully
Listeners: ['192.168.10.11:5100']

Important: Note the UID and listener information from the output. You'll need these for the outbound request.

8.6.2 Step 2: Set Up the Outbound Request (Client Side)

Start the control server on the client side:

vagrant ssh consumers2
s2cs --verbose --port=5007 --listener-ip=192.168.30.10 --type=Haproxy --client-id "abc" --client-secret "xyz"

Initialize the outbound request using the UID and listener from step 1:

vagrant ssh consumer
cp ./vagrant/server.crt ./server.crt
s2uc login --scope "abc"
s2uc outbound_request --s2cs 192.168.30.10:5007 --remote_ip 192.168.20.10 --receiver_ports 5100 4f8583bc-a4d3-11ee-9fd6-034d1fcbd7c3 192.168.10.11:5100

8.7 Testing the Tunnel

8.7.1 Start Server Application

On the server side (producer):

vagrant ssh producer
iperf -s -p 5001

8.7.2 Start Client Application

On the client side (consumer):

iperf -c 192.168.20.10 -p 5100 -t 60

This initiates a 60-second data stream through the tunnel. Data sent to port 5100 on the client side will be securely transmitted to port 5001 on the server side.

8.7.3 Verification

After setting up both sides of the tunnel, verify that the connection works properly:

# Check listening ports
ss -tlpn

8.7.4 Release Resources

When finished, release the allocated resources:

s2uc release 4f8583bc-a4d3-11ee-9fd6-034d1fcbd7c3 --s2cs 192.168.10.11:5007

8.8 Container-Based Deployment

For production environments, you can use container-based deployment:

podman run --rm --net=host -v ./server1:/scistream --entrypoint=s2uc castroflaviojr/scistream:1.2.1 inbound-request --remote_ip 192.168.150.1 --s2cs 192.168.150.1:5000 --receiver_ports 5300 --server_cert=/scistream/server.crt

8.9 Advanced Topics

8.9.1 Implementation Types

SciStream supports multiple data server implementations:

Haproxy
Nginx
Stunnel
StunnelSubprocess
HaproxySubprocess

Specify the implementation type when starting S2CS:

s2cs --type=Haproxy

8.9.2 Port Range Management

Configure port ranges for data transfer:

s2cs --port-range=10000-20000

This restricts SciStream to using ports in the specified range for data forwarding.

8.10 Troubleshooting

8.10.1 Common Issues

Connection Refused Error
Check that the s2cs control server is running on both machines
Verify that the specified ports are not blocked by firewalls
Certificate Issues
Ensure you're using the correct certificate for each machine
Check certificate permissions and paths
UID Mismatch
Double-check that you've correctly copied the UID from the inbound request
Network Configuration
Verify that both machines can reach each other on the specified ports
Check for any NAT or routing issues that might affect connectivity

8.10.2 Diagnostic Commands

# Check for running SciStream processes
ps aux | grep s2

# Check TLS certificate validity
openssl x509 -in server.crt -text -noout

8.11 Quick Reference

Action	Command Template
Start Inbound Request	`s2uc inbound_request --remote_ip <server_ip> --s2cs <server_ip>:5000 --receiver_ports <app_port> --server_cert=<cert_path>`
Start Outbound Request	`s2uc outbound_request --remote_ip <client_ip> --s2cs <client_ip>:5000 --receiver_ports <local_port> --server_cert=<cert_path> <uid> <listener>`
Close Connection	`s2uc release <uid>`
Check Connections	`ss -tlpn`
